Mô tả sản phẩm
| Technical Specifications | PowerMax 2000 |
| Storage Type | Block, file, open systems, IBM i |
| Use Case | Midmarket and enterprise storage, consolidation, transactional workloads |
| Bricks/zBricks | |
| Number of Bricks or zBricks5 | 1 to 2 |
| Engine Enclosure | 4U |
| CPU | Intel Xeon E5-2650-v4 |
| 2.5 GHz 12 core4 | |
| # Cores per CPU/per engine/per system | 12/48/96 |
| Dynamic virtual matrix interconnect | Direct Connect InfiniBand |
| 56 Gbps per port | |
| Maximum IOPS | 2.7 Million |
| Response Times (Reads) | Under 100 microseconds |
| Cache | |
| Cache-system min (raw) | 512 GB |
| Cache-system max (raw) | 4 TB (with 2,048 GB engine) |
| Cache-per engine options | 512 GB, 1 TB, and 2 TB |
| Vault | |
| Vault stratery | Vault to Flash |
| Vault implementation | 2 to 4 NVMe Flash SLICs / Engine |
| Front End I/O Modules | |
| Maximum front-end I/O modules/brick | 8 |
| Front-end I/O modules and protocols supports | 4 x 32 Gbs (FC,SRDF) |
| 4 x 32 Gbs (FC-NVMe) | |
| 4 x 16 Gbs (FC, SRDF) | |
| 10 GbE: 4 x 10 GbE (iSCSI, SRDF) | |
| 25 GbE: 4 x 25 GbE (iSCSI, SRDF) | |
| eNAS I/O Modules | |
| Max eNAS I/O modules / software data mover | 36 |
| eNAS I/O modules support | 10 GbE: 2 x 10 GbE Optical |
| 10 GbE: 2 x 10 GbE Cu1 | |
| 8 Gbs: 4 x 8 Gbs FC (Tape BU)2 | |
| eNAS Software Data Movers | |
| Max software data movers | 4 (3 Active + 1 Standby – 4 Data Movers requires minimum 2 Bricks) |
| Max NAS capacity/array (terabytes usable) | 1158 (cache limited) |
| End-to-end efficient encryption modules | 2 per Brick – Maximum 4 per Array8 |
| Cloud mobility for Dell EMC Powermax Modules | 10GbE: 4 x 10GbE – 1 SLiC dedicated to a single director9 |
| Capacity, Drives | |
| Max Capacity per Array (Open)10 | 1.2 PBe |
| Base Capacity per Brick (NAND, Open) | 13.2 TBu12 |
| Base Capacity per Brick (SCM, Open) | 21.0 TBu14 |
| Base Capacity per zBrick (NAND, Mainframe) | N/A |
| Base Capacity per zBrick (SCM, Mainframe) | N/A |
| Incremental Flash Capacity Packs (NAND) | 13.2 TBu12,16 |
| Incremental Flash Capacity Packs (SCM) | 5.25 TBu15 |
| Max Drives per Brick | 44 Usable + spare(s) |
| Max Drives per Array | 96 |
| Max Drives per System Bay | 96/19211 |
| Min Drive Count per Brick | 4 + 1 Spare |
| NVMe Drives | |
| NVMe Drives Supported (2.5”) | 1.92 TB, 3.84 TB, 7.68 TB, 15.36 TB |
| SCM Drives | |
| SCM Drives Supported (2.5”) | 750 GB, 1.5 TB |
| BE Interface | NVMe over PCIe |
| RAID Options Supported | RAID 5 (7+1) (default) |
| RAID 5 (3+1) | |
| RAID 6 (6+2) | |
| RAID 1 | |
| Mixed RAID Group Support | No |
| Support for Mixed Drive Capacities | Yes13 |
| NVMe Drive Array Enclosure | PowerMax 2000 |
| 24 x 2.5” Drive DAE | Yes |
| Cabinet Configurations | |
| Standard 19″ bays | Yes |
| Single Brick System Bay Configuration | No – (Packaging based on Quad Bricks, but initial Brick in each System Bay supported) |
| Dual/Quad Brick System Bay Configuration | Dual |
| Third Party Rack Mount Option | Yes |
| Dispersion | |
| Standard and 3rd Party Cabinets | N/A – single floor tile system |
| Pre-Configuration From Factory | |
| 100% Thin Provisioned | Yes |
| Host Support | |
| Open Systems | Yes |
| Mainframe | No |
| Mixed Mainframe and Open | No |
| Power Options | |
| Input Power Options | Single or Three Phase |
| Delta or Wye | |
| Front End and SRDF I/O Protocols Supported | |
| 32 Gb/s FC/FC-NVMe Host Ports | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 32 Gb/s FC SRDF Ports | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 16 Gb/s FC Host Ports | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 16 Gb/s FC SRDF Ports | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 16 Gb/s FICON Host Ports | Maximum/Brick: N/A |
| Maximum/Array: N/A | |
| 10 GbE iSCSI Ports (Optical) | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 10 GbE SRDF Ports (Optical) | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 25 GbE iSCSI Ports (Optical) | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| 25 GbE SRDF Ports (Optical) | Maximum/Brick: 32 |
| Maximum/Array: 64 | |
| Embedded eNAS Ports | |
| 10 GbE Optical Ports | Max ports/Software Data Mover: 4 |
| Maximum ports/array: 16 | |
| 10 GbE Copper Ports | Max ports/Software Data Mover: 4 |
| Maximum ports/array: 16 | |
| 8 Gb/s FC Tape Back Up Ports | Max ports/Software Data Mover: 2 |
| Maximum ports/array: 8 | |
| Power consumption and heat dissipation at <26 and >35 degree C | |
| Maximum Total power consumption (kVA) | System bay 1, dual engine |
| <26o C – 4.313 | |
| >35o C – 6.166 | |
| System bay 1, quad engine | |
| <26o C – N/A | |
| >35o C – N/A | |
| System bay 2, quad engine | |
| <26o C – N/A | |
| >35o C – N/A | |
| Maximum Heat dissipation (Btu/hr) | System bay 1, dual engine |
| <26o C – 14,716 | |
| >35o C – 21,038 | |
| System bay 1, quad engine | |
| <26o C – N/A | |
| >35o C – N/A | |
| System bay 2, quad engine | |
| <26o C – N/A | |
| >35o C – N/A | |
| Physical Specifications | PowerMax 2000 |
| Height | System bay, dual engine: 75 inch / 190 cm |
| System bay, dual engine, dual system: 75 inch / 190 cm | |
| Width | System bay, dual engine: 24 inch / 61 cm |
| System bay, dual engine, dual system: 24 inch / 61 cm | |
| Depth | System bay, dual engine: 42 inch / 106.7 cm |
| System bay, dual engine, dual system: 42 inch / 106.7 cm | |
| Weight (maximum) | System bay, dual engine: 950 lbs / 431 kg |
| System bay, dual engine, dual system: 1610 lbs / 730 kg | |
| Input Power Requirements – Single phase | |
| Input nominal voltage | 200 – 240 VAC +/- 10% L- L nom |
| Frequency | 50 – 60 Hz |
| Circuit breakers | 30 A |
| Power zones | Two |
| Power requirements at customer site | Max of two 30A single phase drops per system per cabinet for PowerMax 2000 |
| Quantity one 30A drop per zone for single Brick | |
| Quantity two 30A drops per zone for two Bricks | |
| Max of three 30A, single phase drops (per cabinet) PowerMax 8000 as follows: | |
| Quantity one 30A drop per zone for single Brick | |
| Quantity two 30A drops per zone for two Bricks | |
| Quantity three 30A drops per zone for three or four Bricks | |
| Input Power Requirements – Three-phase | |
| Input nominal voltage | 200 – 240 VAC +/- 10% L- L nom |
| Frequency | 50 – 60 Hz |
| Circuit breakers | 50 A |
| Power zones | Two |
| Power requirements at customer site (min) | Two 50 A, three-phase drops per bay |
| Dell Technologies service | |
| Deployment Services | Dell EMC ProDeploy Enterprise Suite |
| Dell EMC Data Migration Services | |
| Dell EMC Residency Services | |
| Dell EMC Data Sanitization Services for Enterprise | |
| Support Services | Dell EMC ProSupport Enterprise Suite |
| Dell EMC Keep Your Hard Drive for Enterprise | |
| Managed Services | Dell EMC Managed Services for Storage |
| Dell Technologies Consulting Services | Advisory Services and workshops |
| Dell Technologies Education Services | PowerMax technical training courses and certifications |
| Support & Services Technology | MyService360 |
| Secure Remote Services, SupportAssist Enterprise | |
